Production #: M – 4276
ARCHITECT: Richard Bowen Associates – Cleveland, OH
DIMENSIONS: 6 ft projection x 16ft wide w/ arch radius of 39’7″ (up to 10ft projection available)
MATERIAL: All extruded aluminum – 6063-T6
FINISH: 2ct kynar- Mapes charcoal gray.
FASCIA: Standard 8 inch tall extruded aluminum “g” style on all 4 sides (options avail)(.125 Thick)
DECKING: Standard 3” flat soffit style extruded aluminum (.078) Set @ right angles to wall.
HANGER RODS: Optional 1 ¼ inch round powder coated charcoal gray to match. (Standard =1″).
ESCUTCHEON PLATES: Optional design (diamond over square backing plate style) 8 x 8 inch. Powder coated charcoal gray to match canopy finish color. (Hanger rods finished same).
WALL ATTACHMENT: Custom bolt style (included) at upper & lower attachment points.
DRAINAGE: Standard perimeter fascia scuppers. (Optional downspouts available).
FINISH OPTIONS: Clear anodized. Bronze and white baked enamel.
