Offices of Economic Development

Hermitage, PA

Project Number: M-4835
CATEGORY: Super Lumideck

Project Details


ARCHITECT: HHSDR Architects & Engineers – Sharon, PA

MATERIAL: All extruded aluminum 6063-T6.

FINISH: Mapes standard clear anodized.

DIMENSIONS: Forward curved unit shown: length / width of front arc: 32 ft . Canopy projection: 5 ft.

TALL FASCIA: Optional 16 inch tall “c” style bent plate style on 3 sides. The 16 inch fascia is attached to the face of standard “g” style fascia. Integral “g” style fascia/ gutter system used on all 4 sides of canopy. The bent plate “c” style is 1/8” thick plate aluminum w/ 1 ½ inch inward facing legs.

STANDARD FASCIA: Becomes sub fascia and acts as 4 sided perimeter gutter. Standard fascia material: 8 inch tall extruded aluminum “g” style on 4 sides (.125 thick).

STANDARD FASCIA NOTE: The standard 8 inch tall fascia follows the building arc at both the front and back of the canopy and follows the wall face arc at the back.

DECKING: Mapes standard 2 ¾ deep style; 6063- t6 extruded alum (.078 thick), set at right angles to wall.

HANGER RODS: Standard 1 inch diameter powder coated to match canopy finish color.

HANGER ROD CONFIGURATION: 4 rods total – custom “splayed style” to accommodate 2 structural attachment points at wall face while supporting canopy deck at 4 points.

ESCUTCHEON PLATES: Standard 3 inch diameter x ¼ inch thick powder coated to match.

WALL ATTACHMENT: Upper and lower attachment locations: through bolts into structural steel framing behind “efis” exterior insulation and finish system wall face. Through bolts / anchor bolts , including steel compression tubes, provided by Mapes with lengths as required.

DRAINAGE: Mapes standard downspouts at back wall draining into underground leaders. (Standard scuppers are available).

FINISHES AVAILABLE: Clear anodized. Bronze or white baked enamel.
