PRODUCTION #: M-3954
ARCHITECT: Wakefield / Beasley Associate Arch. – Norcross, GA
MATERIAL: All extruded aluminum 6063-T6.
FINISH: Standard clear anodized.
DIMENSIONS: 2 units: 5 ft. projection x 17 ft. wide
FASCIA: “Double stacked” standard 8 inch tall extruded aluminum “G” style, with second fascia set above with .5″ offset.
DECKING: Mapes standard 2.75″ flat soffit style; 6063- T6 extruded aluminum (.078″ thick) running parallel to walls.
HANGER RODS: Standard 1″ round powder coated to match canopy finish color.
ESCUTCHEON PLATES: Standard 7” x 7” aluminum set in square orientation at wall face, powder coated to match
WALL ATTACHMENT: Thru bolts (included) at upper and lower attachment locations.
DRAINAGE: Standard perimeter fascia scuppers (optional downspouts available).
FINISHES AVAILABLE: Clear anodized. Bronze or white baked enamel. Standard and custom kynar colors available.
